PART NAME : MAIN PCB ASS'Y
6100-PNC-0909-0 PCB-MAIN 6100-PNC-0909-0 1 2006.07
6220-IS0-2575-0 IC(REGULATOR) LM2575-5S(TO-263(S)) 1 U6
6200-IPU-0676-0 IC(CPU) PIC16F676(DIP) 1
U7
6240-IS0-2277-0 IC(OP AMP) OPA2277UA(SMD)NT-300 1 U8
6200-IPU-0845-0 IC(CPU) ADUC845BS62-5(NT-300) 1 U9
6210-IS0-1274-0 IC(RESET) TC1274 1 U10
7010-ZK0-3276-0 CRYSTAL 32.768KHz 1 Y1
6281-I00-2222-0 TRANSISTOR CHIP 2N2222AS 1 Q2
6281-I00-1504-0 TRANSISTOR CHIP KTA1504 SY 1 Q3
6294-ICP-0184-0 DIODE-CHIP KDS184 1 D1
6291-IS0-5819-0 DIODE POWER 1N5819(SMD) 1 D2
6804-F00-1004-0 LINE FILTER T1004(HM3A) 1 L3
7002-Z00-0120-0 PIEZO BUZZER 14A4012P(EFM-250A) 1 BZ1
6550-M09-0223-0 RESISTOR-NETWORK M9-223 1 AR1
6527-ID3-0047-0 RESISTOR-CHIP 1/10W
RR1220P-472D(4.7㏀)
3 R12, 14, 27
6527-ID3-0200-0 RESISTOR-CHIP 1/10W RR1220P-203D(20K) 1 R13
6527-ID3-0010-0 RESISTOR-CHIP 1/10W RR1220P-103D(10K) 2 R15, 16
PART NAME : DISPLAY PCB ASS'Y
6110-PNC-0909-0 PCB-DISPLAY 6110-PNC-0909-0 1 2006.07
6224-I00-7225-0 IC(DRIVER) UPD 7225G00 1 U1
7212-D00-8430-0 LCD DTE 101710 ACP 1(NC) 1 U2
7244-D00-0005-A E.L.INVERTER MTED-I-5C 1 U3
7222-D00-0025-A E.L.BACK LIGHT MT-NC1-RO 1 U4
7240-DRM-2043-0 REMOCON MODULE
PIC-
12043TM(KSM64LM)NC,CASTON
1 U5
6281-I00-1504-0 TRANSISTOR CHIP KTA1504 SY 1 Q1
7232-DRG-0003-0 LED LAMP ø3-(R,G) BL-BVT 201(ANODE) 1 LD1
7232-D00-0300-0 LED LAMP CLL302341(BVL-300E5G) 1 LD2
6527-ID3-0010-0 RESISTOR-CHIP RR1220P-101D(1K) 7 R1~4, 6~8
6527-ID3-1800-0 RESISTOR-CHIP RR1220P-184D(180K) 1 R5
6527-ID0-0020-0 RESISTOR-CHIP
RR1220P-2R0D(2Ω)
1 R9
6527-ID3-0047-0 RESISTOR-CHIP RR1220P-472D(4.7K) 2 R10, 11
6712-CHP-0103-0 CONENSER-CHIP CL21F 103KBNC 1 C1
6712-CHP-0104-0 CONENSER-CHIP CL21F 104KBNC 16 C2, 3, 8~21
6712-CHP-0102-0 CONENSER-CHIP CL21B 102KBNC 4 C4~7
6670-T00-0220-0 INDUCTANCE 220uH 2 L1, 2
7805-CCN-6708-0 CONNECTOR(WAFER) 08-5267 2 CN1, 2
