11. PARTLIST
NC-30N
PART CORD NAME SPECIFICATION Q'TY REMARK
PART NAME : CHARGER PCB ASS'Y
6151-PNC-0430-0 PCB-CAL 6151-PNC-0430-0 1 2005.09.21
7600-SLD-0002-0 SLIDE S/W INCA-2(DJMM-12V) 2 CAL, POWER
7804-CCN-7303-0 CONNECTOR(WAFER) 5273-03 (LPH03-03) 1 CN1
7805-CCN-6703-0 CONNECTOR(WAFER) 03-5267 1 CN2
7840-W00-B215-0 CONNECTOR WIRE 2P*150mm(NC-N) 1 connector wire of CAL
7840-W00-A215-A CONNECTOR WIRE 2P*150mm(NC-N) 1 connector wire of ADAPTOR
7840-W00-0330-0 CONNECTOR WIRE 3P*300mm(NC-N) 1 connector wire of BATTERY
PART NAME : CHARGER PCB ASS'Y
6171-PC5-6170-0 PCB-RECHARGE PCB-CHARGE 1 2006. 09
6200-IPU-0676-0 IC(CPU) PIC16F676(DIP) 1 U1
6241-I00-0317-0 IC(LINEAR) LM-317T 1 U2
6220-I00-7805-0 IC(REGULATOR) TA7805S 1 U3
6273-IS0-6679-0 FET FDS6679 1 Q1
6280-IS0-7002-0 TRANSISTOR 2N7002 1 Q2
6294-ICP-0240-0 DIODE-CHIP B240 1 D1
6291-IP0-4007-0 DIODE-POWER 1N5819 3 D2, 3
7600-SDP-0002-1 DIP S/W KSD-02S(SMT)(NT-300) 1 SW1
6515-CJ3-0470-0 RESISTOR 1/4W CFR 47K(±5.0%) 1 R1
6515-CJ3-0010-0 RESISTOR 1/4W CFR 1K(±5.0%) 2 R2, 4
6512-CJ0-0033-0 RESISTOR CFR 3.3/2W(±5.0%) 1 R3
6505-MF3-0080-0 RESISTOR 1/4W MFR 8K(±1.0%)-F 1 R5
6505-MF3-0040-0 RESISTOR 1/4W MFR 4K(±1.0%)-F 1 R6
6505-MF3-0020-0 RESISTOR 1/4W MFR 2K(±1.0%)-F 1 R7
6505-MF3-0018-0 RESISTOR 1/4W CFR 1.8K(±5.0%) 1 R8
6505-MF3-0012-0 RESISTOR 1/4W CFR 1.2K(±5.0%) 1 R9
6515-CJ3-0330-0 RESISTOR 1/4W CFR 33K(±5.0%) 1 R10
6710-CAP-0104-0 CONDENSER-CERAMIC 0.1UF/50V 3 C1, 2, 5
6704-C25-0470-0 CONDENSER-ELECTRIC 470UF/25V 2 C3, 4
7805-CCN-6704-0 CONNECTOR(WAFER) 04-5267 1 CN1
7805-CCN-6703-0 CONNECTOR(WAFER) 03-5267 1 CN2
7805-CCN-6708-0 CONNECTOR(WAFER) 08-5267 1 CN3
7805-CCN-6702-0 CONNECTOR(WAFER) 02-5267 1 CN4
