CAS NC-1 - Page 73

74
PART NAME : REMOCON MODULE PCB ASS'Y
1060-A00-0012-0 PCB CONTACT
8*8.4*8.6(C-Ⅲ)
2
6170-PCA-6160-0 PCB-REMOCON
6170-PCA-61600(C-Ⅲ)
1
6222-I00-9802-0 IC(REMOCON) KS 9802(THA) 1
6280-I00-1015-0 TRANSISTOR 2SA1015(1266) 1
6280-I00-1815-0 TRANSISTOR 2SC1815A(3198) 1
6294-ISW-4148-0 DIODE-SWITCHING 1N4148P 3
6515-CJ0-2200-0 RESISTOR 1/4W CFR 220 (±5%) 1
6515-CJ3-0100-0 RESISTOR 1/4W CFR 10K (±5%) 1
6704-C16-0047-0
CONDENSER-
ELECTRIC
47uF/16V 1
6710-CAP-P101-0
CONDENSER-
CERAMIC
100PF/50V 2
6802-F00-0455-0 CERAMIC FILTER CSB 455 E 1
6S70-PCA-6160-0
PCB-REMOCON
INSERT
6170-PCA-61600(C-Ⅲ)
1
7232-D00-0300-0 LED LAMP CLL30231(BVL-300E5G) 1
7235-D00-8925-0 IR-LED OSI-8925(C-2,3) 1
PART NAME : BODY ASS'Y
1030-A00-0025-0 BATTERY HOLDER 67*47*21*1T(NC-1) 1
1030-A00-0041-0 BRACKET-KEY 108*35*1.2T(NC-1) 1
1030-A00-0042-0 BRACKET-LCD 179*64*1T(NC-1) 1
1030-A00-0043-0 BRACKET-JACK 46*41*1.8T(NC-1) 1
1030-A00-0044-A PCB-SHIELD CASE 181*117*1.5T(NC-1) 1
1030-A00-0045-0 BRACKET 40*39*2T(NC-1) 1
1030-A00-0046-0 UPPER PLATE ø28*15*2T(NC-1) 1
1090-NC0-0001-0 BATTERY SHEET 79*66*0.4T(NC-1) 0.01
1100-A00-0018-0 FRONT COVER 260*161*110(NC-1) 1
1100-A00-0019-A REAR COVER 255.4*156*36(NC-1) 1
1131-A00-0001-0 HOOK SWL-1TON(NC) 1
1132-A00-0002-0 SPLIT PIN 3*50(NC-1,THA) 1
1132-A00-0003-0 SHACKLE SWL-2T*1/2(NC) 1
1210-A00-0043-0 BOSS SUPPORT M4*51(NC-1) 1
1210-A00-0051-0 GUIDE SHAFT B ø38*152(NC-1) 1
1210-A00-0052-0 HOUSING A ø45*65(NC-1) 1
1210-A00-0054-0 LOAD PIN ø16*54(NC-1) 1
1210-A00-0055-A GUIDE SHAFT A
ø30*113(NC-1)공용
1
1215-A00-0115-0 BOLT-CONNECTOR M4*30*6(EXP-5000) 2
PCB-SHIELD CASE 지지 볼트
1260-A00-0002-0 BOLT-SEALING M4*13(S-2000) 1
1260-A00-0004-0 BOLT-SEALING M10*8 1
