CAS PB Series User Manual

1
7
SPECIFICATIONS
MODEL PB(LCD)
Capacity / e
Dual Interval
Max15/30kg
e=5/10g
Dual Interval
Max 30/60kg
e=10/20g
Dual Interval
Max 60/150kg
e=20/50g
Dual Interval
Max 100/200kg
e=50/100g
Internal
Resolution
1/60000 1/60000 1/60000 1/60000
External
Resolution
1/3000 1/3000 1/3000 1/2000
MAX Tare -14.995kg -29.99kg -59.98kg -99.95kg
Display 134 x 48.6[mm]/52.7" x 19.1" 6digit LCD
Symbols STABLE, ZERO, TARE, g, kg, lb, oz, Low Battery
Keys ZERO, TARE, HOLD, POWER
Functions
Weighing Hold Function
Backlight ON/OFF(Bright) Control Function
Auto Power Off Function
Print out Function
Dimensions 355(W) x 611(D) x 65(H)[mm] / 140(W) x 241(D) x 256(H)[inch]
Platter size 355(W) x 443(D)[mm] / 140(W) x 174(D)[inch]
Weight 6.0kg
Power 1.5V x 4 units (C size Battery)
Operation
Time
Approx. 140hours (Manganese battery)/
300hours (Alkaline at 20°C /68°F)
Operating
Temperature
-10°C ~ +40°C / 14°F ~ 104°F
Minimum
Voltage
Level of The
Battery
About 4.2V(Recharge Battery: 5.6V)
Option
12V Adaptor 1.5A
RS-232C(RJ-11 TO D-SUB) Wire (Add Serial Interface)
DEP-50 Printer (Add Serial Interface)
Recharge battery(Pb:6V, 1.3Ah, 20HR) (Add Recharge Interface)
Notice: Specificati※ ons are subject to change for improvement without notice.

CAS PB Series Specifications

General

Display	LCD
Overload Protection	Yes
Units	g, oz
Interface	RS-232 (optional on some models)
Auto Calibration	Yes
Operating Temperature	10°C to 40°C
Material	Stainless steel platform, ABS housing
