3-CONTROLSANDINSTRUMENTS
Operator'sseat
Operator'sseat
Suspensionseat(withoutROPS)
Forward/Reverse
Handleislocatedonthefrontsideoftheseatlifttheseat
adjustmenthandle(1)tomovetheseatforwardorre-
verse.Releasetheseatadjustmenthandle(1)anden-
suretheseatislockedinposition.
PTIL16TLB0374AA1
Rotatetheseat
Leverislocatedontheleft-handsideoftheseat.Liftthe
lever(1)andhold.Turntheseattothedesiredposition
andreleasethelever(1)tolock.
NOTE:Theoperatorseatwillrotate90°onright-hand
side.
PTIL16TLB0371AB2
Height
Usethehandcrankontheknob(1).Turntheknob(1)
clockwisetoincreasetheseatheightandsuspensionrm-
ness.Turncounter-clockwisetodecreasetheseatheight
andsuspensionrmness.
PTIL16TLB0372AB3
