4-OPERATINGINSTRUCTIONS
Movingtheunit
Movingtheunit
Beforeoperatingthemachine
WARNING
Equipmentfailurecouldcauseaccidentorinjury!
Beforeoperatingthemachine,checkforcorrectoperationofsteering,brakes,hydrauliccontrols,
instruments,andsafetyequipment.Makesurethetransmissioncontrolleverisintheneutralposition.
Makealladjustmentsbeforeoperatingthemachine.
Failuretocomplycouldresultindeathorseriousinjury.
W0204A
Checktheinstrumentpanel
Testtheparkingandservicebrakes.
NOTE:Reviewtheproceduresintheirentiretybeforeproceeding.Ensureyouallowsurplusroomformachinetravel
onslope.
1.T otesttheparkingbrake:
○
Ensuretheoperator’sseatisinnormalposition.
○
Ensurethatarticulationjointarrestorisdisengaged.
○
Ensurethatparkingbrakeisnotengaged(parkingbrakeshouldbeinoffposition).
○
Startuptheengine.
○
Increasetheenginespeedtofullthrottle.
○
Travelforwardonslope.
○
Onslopeputtheforwardreverselever(FNR)inneutralandengagetheparkingbrakeorshutdowntheengine.
○
Parkingbrakewillholdthem/c.
○
Contactyourdealerforservicesasneeded.
2.Thehydrostaticsystemconstitutestheservicebrakethusaseparateservicebrakeinnotrequired.Thespring
loadedmultiplediscbrakesintherearaxleservesasaparkingbrake.
Operatingthemachine(travel)
1.Drivethemachinewiththedriveleverintothedesireddrivingdirection.Ifthedriverleverismovedforwardfrom
neutralposition,themachinewillmoveforward.
Ifthedriverleverismovedbackwardfromneutralposition,themachinewillmovebackward.
Thespeedwillincrease,themoretheleverismovedforwardorbackward.Forbraking,movethedriveleverout
oftherespectiveforwardorreversedrivingpositiontotheneutralposition.
2.Duringparkinginslope,switchonparkingbrakeswitch(P).
ATTENTION:Parkingbrakeistobeoperatedonlywhenthemachineisinneutral.Electricalsystemisdesignedin
suchawaythatparkingbrakewillbeengagedonlywhentheforwardreverselever(FNR)isinneutral.
4-9
