5-TRANSPORTOPERATIONS
Recoverytransport
Towingthemachine
WARNING
Lossofcontrol!
Onlytowatsafespeeds.Usecautionwhenmakingcornersormeetingtrafc.
Failuretocomplycouldresultindeathorseriousinjury.
W0126A
NOTICE:Towingthecompactorisnotsuggested.
NOTICE:Thecompactorengineshouldnotbestartedbytowingthemachine.Thedrivetraincomponentswillbe
damaged.
Ifyourmachineisdisabled,youmustmakeajudgmentifthemachinecanbemovedwithoutdamage.Ifpossible
repairthemachineatthejobsite.
Themachinemustbeattachedascloseaspossible.
Thedisabledmachinemustbemovedonlyfarenoughtoreachasaferepairlocationorontoatrailer.
Beforemovingadisabledmachine,youmustbeabletoanswerthesequestions:
•
Doesthetowingmachinehavebrakingandsteeringcapacityforboththemachines?
•
Doesthetowinghardware,chains,cableshavethepropercapacitytomovethemachinesafely?
•
Willthedisabledmachinehavesteeringandbrakingcapability?
•
Whilemovingthemachine,itwillcausedamagetodrivetrainormovingpartsthatlacklubrication?
Additionalconsiderations
•
Becertainthatallpersonnelinvolvedareshieldedintheeventthattowingapparatusmightbreak.
•
Anoperatormayonlybeallowedonthetowedvehicleifithassteeringandbrakingcapability.
•
Alwaysblockthedisabledmachinewheelsbeforereleasingthebrakesordrivetraincomponent.
Towing
Usethelugsatthefrontandrearrollerframefortowing.
Fixthearticulationjointarrester.Interconnect“A”and“B”
portoftravelpumpbyturningthescrewsonmainrelief
valve.
Releasingbrakeonaxle
1.SwitchOFFtheengineandtheparkingbrakeswitch.
2.Closethevalve(1)belowtheoperator’splatformetc.
