3-CONTROLSANDINSTRUMENTS

6.ParkingBrakeIndicator

Parkingbrakeindicatorglowswhenparkingbrakeisen-

gaged.Parkingbrakedisengageswhenthetravelcon-

troller(FNR)isforward/reverseposition.Iftheparking

brakeisnotdisengaging,thisindicatorcomesON.Shut

offtheengineimmediately,locatethecauseandsetright

theproblem.

PTIL14COM0033AA7

7.HighCoolantTemperatureIndictor

ThisindicatorcomesONwhenthecoolanttemperatureof

enginegoesinthedangerouszonealongwiththecontin-

uosbuzzersound.Shutdowntheenginetillthenormal

temperatureoftheenginecoolant.

PTIL15COM0046AB8

8.LowLubricationOilPressureIndicator

ThisindicatorcomesOnwhenthelubricationoilpressure

fallsbelowapresetlevel.ShutOfftheengineimmedi-

ately,locatethecauseandsetrighttheproblem.

PTIL15COM0047AB9

3-8
