3-CONTROLSANDINSTRUMENTS

9.HydraulicFilterClogIndicator

ThisindicatorcomesONwhenthehydraulicoillterclogs.

Stopthemachineoperationandreplacethelterelement.

Runningthemachineafterltercloggingwillcontaminate

thehydrauliccircuitandcancauseextensivedamageto

thehydraulicsystem.

PTIL15COM0048AB10

10.LeftDirectionIndicator

ThisindicatorcomesONwithselectionoftheLHdirection

selectionswitch.

PTIL15COM0049AB11

11.RightDirectionIndicator

ThisindicatorcomesONwithselectionoftheRHdirection

selectionswitch.

PTIL15COM0050AB12

3-9
