3-CONTROLSANDINSTRUMENTS
12.Voltmeter
Thisshowthevoltagedifferencebetweenthetwobattery
terminalsitisusedtocheckthebatteryconditionsideally
itshouldbebetween11to14volts,elsebatteryneedsto
bechecked.
PTIL15COM0078AB13
13.TestButton
Thisbuttonisusedtotestthefunctioningoftheindicator
bulbs.Whenthebuttonisdepressedindicatorsshould
comeON.(Neutralstartswitchlight,parkinglight,water
hightemp,lowlubeoilpressure,hydraulic.lterclog.)
PTIL15COM0052AB14
14.HornSwitch
Depressthehornswitchtoblowhorn.
PTIL15COM0053AB15
3-10
