3-CONTROLSANDINSTRUMENTS

21.WaterPumpSwitch

Toswitch"ON"waterpump,rotatethewaterpumpswitch.

PTIL15COM0060AB22

22.BothDrumHighOrLowFrequency

Switch

Tooperatethemachineinbothdrumhighorlowfre-

quencymode,selectthedesiredmodebyrotatingthe

switch.

PTIL15COM0061AB23

23.FrontDrumHighOrLowFrequency

Switch

Tooperatethemachineinfrontdrumhighorlowfre-

quencymode,selectthedesiredmodebyrotatingthe

switch.

PTIL15COM0062AB24
