3-CONTROLSANDINSTRUMENTS
24.MCB
Tostarttheengine&ignitionrstswitchONtheMCB.
MCBwilltripifanyelectricalfaultoccursinmachine.
PTIL15COM0063AB25
25.HazardSwitch
Hazardpushbuttonisplacedatlefthandofthecontrol
tower.AfterpushingthehazardswitchbothLH/RHindi-
catorwillglowsimultaneously.
PTIL15COM0051AB26
3-14
