CASE CONSTRUCTION 450DX - Main Components Identification

8-SPECIFICATIONS
15
RearT ankCover
32
SprinklerAssembly
16
CanopyRoof
33
Operator'sSeatAssembly
17
Engine
34
SteeringWheel
1.FrontRollerAssembly
ThefrontrollerassemblyisCoupledtothefrontchassis
withthehelpofleft&rightsupportingbracket.
PTIL15COM0204AA2
2.RearRollerAssembly
Sameasfrontrollerassembly.
PTIL15COM0205AA3
3.FrontChassisFrame
Thefrontchassisframesupportsthefrontrollerassem-
bly,Vibrationmotor,Frontpropulsionmotor,engine&its
accessories,waterhydraulicoiltank.Thefrontchassisis
connectedtotherearchassisbymeansofanArticulation
joint.
PTIL15COM0206AA4
8-16
