CASE CONSTRUCTION 450DX

To Next Page

To Previous Page

8-SPECIFICATIONS

16.CanopyRoof

Astylish,lightweightcanopyroofismountedoverthe

canopysupportjustabovetheoperatorsseat.Itprotects

theoperatorfromthescorchingraysofthesunandrain.

PTIL15COM0019AC17

17.Engine

AWatercooled,Naturallyaspirateddieselengineis

mountedonthefrontchassisinthetransversedirection.

PTIL15COM0220AA18

18.RadiatorOilCoolerAssembly

Radiatorprovidedisprimarilyaheatexchangerwhichis

coupledalongwiththeoilcoolertokeepthetemperature

ofthecoolantundercontrol.

PTIL15COM0221AA19

8-21
