8-SPECIFICATIONS

19.AirPreCleaner

Airprecleanerismountedontheradiatorsideoftheen-

gine.Itsprimaryobjectiveistosegregatedustparticles

fromtheincomingairow.

PTIL15COM0022AB20

20.AirCleaner

Asingleelement,wettype,heavydutyairlterisprovided

alongwiththeengine.thereisavacuumindicatorwhich

indicatesthechokingoftheairlter.

PTIL15COM0023AB21

21.EngineLubeOilFilter

EngineLubeoillterismountedonengineusedtosepa-

rateforeignmaterialfromengineoil

PTIL15COM0224AA22

8-22
