12 - INFORMATIONAL DECALS
INFORMATIONAL DECALS
Decals With “Read Operator’s Manual” Symbol
Decals which display the “Read Operator’s
Manual” symbol are intended to direct the operator
to the Operator’s Manual for further information
regarding maintenance, adjustments and/or
procedures for particular areas of the Combine.
When a decal displays this symbol refer to the
appropriate page of the Operator’s Manual as
given below.
782L95
DECAL LOCATION DESCRIPTION PAGE
1. Operator’s Manual Pouch Manual Storage 2
2. Cab Back Wall Do Not Block Cab Recirculation Air Filter 59
3. Cab Headliner Hazard Warning
Park Brake Disable
11, 55
4. Cab Headliner Upper Relay Identification 417
5. Cab Lower Fuse Box Lower Fuse and Relay
Identification
418
6. Operator’s Ladder Upper and Lower Control 142
7. Lubrication Decals
Left Side 10 to 100 Hour Intervals 267, 285
Right Side 10 to 100 Hour Intervals 270, 286
Top 10 to 100 Hour Intervals 264, 284
Rear Axle 10 to 100 Hour Intervals 275, 288
