4 - INSTRUMENTS/CONTROLS
49
RD97G033
20. HEADER RAISE RATE CONTROL - Sets the rate at which the header raises. It functions
in all modes of header operation.
21. HEADER LOWER RATE CONTROL - Sets the rate at which the header lowers. It
functions in all modes of header operation.
22. ACCUMULATOR SWITCH (If Equipped) - The operator can enable or disable the
accumulator system at any time.
NOTE: The position of the feeder no longer enables or disables the accumulator system.
NOTE: The header raise and lower rate controls and minimum reel speed control are located under the right hand
arm rest.
20
21
22
