SECTION 2 - CONTROLS, INSTRUMENTS AND OPERATION
2ï8
Model
Horsepower rating
Model
Horsepower rating
LB323 Standard
75 kW (102 hp)
LB423 Standard
90 kW (122 hp)
LB323 Packer Cutter
80 kW (110 hp)
LB423 Rotor Cutter
110 kW (150 hp)
LB323 Rotor Cutter
95 kW (130 hp)
LB433 Standard
90 kW (122 hp)
LB333 Standard
75 kW (102 hp)
LB433 Rotor Cutter
110 kW (150 hp)
LB333 Packer Cutter
80 kW (110 hp)
LB333 Rotor Cutter
95 kW (130 hp)
TRACTOR DRAWBAR / TOW HITCH
The tractor drawbar or tow hitch must be able to carry on its end a weight (depending on the Baler Type, for
example type (6RL):
The number denotes Knotters, 4 = 4 Knotter, or 6 = 6 Knotter,
1st letter denotes baler configuration S = Standard, P = Packer, R = Rotor
2nd letter denotes axle type S = Single axle, T = Tandem axle, L = Large tandem axle
Baler Type
Mass
Weight at drawbar
6RL
1900 daN
1900 kgs (4188 lbs)
4RL
1650 daN
1650 kgs (3637 lbs)
6RT
1600 daN
1600 kgs (3527 lbs)
6RS
1600 daN
1600 kgs (3527 lbs)
4RS
1500 daN
1500 kgs (3306 lbs)
4RT
1400 daN
1400 kgs (3086 lbs)
6ST
1350 daN
1350 kgs (2976 lbs)
6SS
1350 daN
1350 kgs (2976 lbs)
4PT
1300 daN
1300 kgs (2866 lbs)
4PS
1300 daN
1300 kgs (2866 lbs)
4ST
1200 daN
1200 kgs (2645 lbs)
4SS
1200 daN
1200 kgs (2645 lbs)
NOTE: The drawbar must be a clevis type drawbar.
