2. Connect the baler to the tractor (wheels set), check dimension hitch height if the delta is more than 18
mm(0.7in) change position. After conversion tighten the bolts to: 304-335 Nm (224.2-247 lbs ft).
3. Measure PTO height tractor (Dimension B) min. of one position overlaps max. of next position), check
list and choose the PTO position that is closest to this dimension in the following table and illustration.
Tractor PTO height (B)
Machine type
Rotor Cutter
Standard / Packer Cutter
Axle
Large steered
tandem axle
Single axle
Tandem/
Str
tandem
Large
steer
tandem
Single
axle
Single
axle
Tandem/
Steer
tandem
Tyre dimension
560/45
R22.5
620/50
R22.5
600/55
22.5
710/40
R22.5
500/50
17.0
560/45
R22.5
710/40
R22.5
600/55
22.5
500/50
17.0
PTO Height Tractor
530 mm
(20.9 in)
550 mm
(21.7 in)
-
-
-
-
-
2 Low
2 High
2 Low
550 mm
(21.7 in)
570 mm
(22.4 in)
-
1 Low
-
-
-
2 High
2 High
2 Low
570 mm
(22.4 in)
590 mm
(23.2 in)
1 Low
1 Low
-
1 Low
-
2 High
3 Low
2 Low
590 mm
(23.2 in)
610 mm
(24.0 in)
1 Low
1 Low
1 Low
1 Low
1 Low
3 Low
3 Low
2 High
610 mm
(24.0 in)
630 mm
(24.8 in)
1 Low
1 Low
1 Low
1 Low
1 Low
3 Low
3 Low
2 High
630 mm
(24.8 in)
650 mm
(25.6 in)
1 High
1 Low
1 Low
1 Low
1 Low
3 Low
3 High
2 High
650 mm
(25.6 in)
670 mm
(26.4 in)
1 High
1 High
1 Low
1 High
1 Low
3 High
3 High
3 Low
670 mm
(26.4 in)
690 mm
(27.2 in)
1 High
1 High
1 High
1 High
1 High
3 High
4 Low
3 Low
690 mm
(27.2 in)
710 mm
(28.0 in)
1 High
1 High
1 High
1 High
1 High
3 High
4 Low
3 High
710 mm
(28.0 in)
730 mm
(28.7 in)
2 Low
1 High
1 High
1 High
1 High
4 Low
4 Low
3 High
730 mm
(28.7 in)
750 mm
(29.5 in)
2 Low
2 Low
1 High
2 Low
1 High
4 Low
4 High
3 High
750 mm
(29.5 in)
770 mm
(30.3 in)
2 Low
2 Low
2 Low
2 Low
2 Low
4 Low
4 High
4 Low
770 mm
(30.3 in)
790 mm
(31.1 in)
2 High
2 Low
2 Low
2 Low
2 Low
4 High
4 High
4 Low
790 mm
(31.1 in)
810 mm
31.9 in)
2 High
2 High
2 Low
2 High
2 Low
4 High
5 Low
4 Low
