Figure 215
Th e elec t r i c a l c o mpo n en t s provided w it h F4BE 0484
Engine are listed here following:
1. Cooling liquid temperature sensor;
2. S tarter;
3. KSB Water temperature sensor;
4. Electromagnets assemb led to feed pump:
(A) on hydr aulic head unit
(B) on KKSB;
5. Fuel heater;
6. O il pressure switch;
7. Resistor for c old start (whether specifically designed);
8. Alt ernat or;
1
2
3
4
5
6
7
8
A
B
75724
SECTION 3 − DUTY − INDUSTRIAL APPLICATION E NG I NE S
75
ED. FEBUARY 2003
ELECTRICAL COMPONET LAYOUT (4 CYL. ENGINES WITH ROTARY POMP)
