SECTION 4 − OVERHAUL AND TECHNICAL SPECIFICATIONS
ENGINES 9
ED. FEBUARY 2003
Ty p e 4CYLINDERS 6CYLINDERS
CYLINDER HEAD — TIMING SYSTEM mm
∅
1
Tappet cap housing
on block ∅ 1−
∅
2
3
∅
∅
2
Tappet cap outside
diameter: ∅ 2
∅ 3
15.924 to 15.954
15.965 to 15.930
Between tappets and housings 0.025 to 0.070
Tappets −
∅
1
Rocker shaft ∅ 1 21.963 to 21.975
∅
2
Rockers ∅ 2 19.000 to 19.026
Between rockers and shaft 0.025 to 0.063
