Case 445T/M2 - Page 6

ENGINES
4
ED. FEBUARY 2003
Graph and symbols
Removal
Disconnection
Intake
Refitting
Connection
Exhaust
Removal
Disassembly
Operation
Fitting in place
Assembly
ρ
Compression ratio
Tighten to torque
To l e r a n c e
Weight difference
α
Tighten to torque + angle value Rolling torque
Press or caulk
Regulation
Adjustment
Rotation
!
Warning
Note
Angle
Angular value
Visual inspection
Fitting position check
Preload
Measurement
Value to find
Check
Number of revolutions
Equipment Te m p e r a t u r e
Surface for machining
Machine finish
bar
Pressure
Interference
Strained assembly
Oversized
Higher than….
Maximum, peak
Thickness
Clearance
Undersized
Less than….
Minimum
Lubrication
Damp
Grease
Selection
Classes
Oversizing
Sealant
Adhesive
Te m p e r a t u r e < 0 °C
Cold
Winter
Air bleeding
Te m p e r a t u r e > 0 °C
Hot
Summer
