INTRODUCTION
Relayicondenitions
Symbol
Function
AUXmainrelay
SCRmainrelay
Sideconsolefuseandrelaypanel(undertheinstrumentcluster)
PowerShuttlePowershift
47747128_B6
Relayicondenitions
Symbol
Function
Four-WheelDrive(4WD)relay
NOTE:MachineswithH-TypePowershiftonly.
Autoengineshutdownrelay
Shutdownrelay1
Shutdownrelay2
