Case 580SN - Assembly Method and Verification

INTRODUCTION
Assemblymethodandverication:
1.AligntheSTC®ttingonthehoseassemblywiththe
STC®connector.
2.Pushthehosettingintothematingconnectoruntil
youfeeladenitesnapandasolidstop.
NOTE:Besurethatthedirectionofpullisparallelto
theaxisoftheSTC®connection.
3.VerifythattheSTC®connectionhasbeenmadesuc-
cessfullybypullingontheconnectiontomakesure
thatthemaleconnectorhasbeenproperlyinserted
intofemaleconnector.
RAIL17TLB0015AA7
RAIL17TLB0014AA8
RAIL17TLB0013AA9
4819455820/10/2017
65
