Case 580SN - Front Console Fuse and Relay Panel

To Next Page

To Previous Page

INTRODUCTION

Frontconsolefuseandrelaypanel

PowerShuttlePowershift

47747127_A5

Fuseicondenitions

Symbol

Function

Hazardlights

CrankcaseVentilation(CCV)heater

UnswitchedBattery+toSCRpumpmodule

UnswitchedBattery+toSCRheatvalveandpump

UnswitchedBattery+toT4Bandureasensors

By-passrelaybattery+

AUXmainrelay,electricvalve,by-passrelaycoilpower

ECUBattery+Band+C

ECUBatteryvoltage
