Case 580SN - Transmission

INTRODUCTION
Transmission
Standardspecication(factoryll):CASEAKCELANEXPLORE™FLUID
SCWPspecication(factoryll):CASEAKCELAHY-TRAN®ULTRACTIONSSL
Manual(powershuttle)
TwowheeldriveFourwheeldrive
Totalsystem
17.0l(18USqt)19.4l(21USqt)
Rell(withorwithoutlterchange)10.5l(11USqt)13.0l(14USqt)
PowershiftS-type
TwowheeldriveFourwheeldrive
Totalsystem
21.7l(22.9USqt)20.7l(21.9USqt)
Rell(withorwithoutlterchange)15.3l(16.2USqt)14.3l(15.1USqt)
PowershiftH-type
Fourwheeldriveonly
Totalsystem
18.0L(19.0USqt)
Rell(withorwithoutlterchange)11.4L(12.0USqt)
NOTE:Themasterbrakecylinderreceivesuidfromthetransmission.
NOTE:CASEAKCELAHY-TRAN®ULTRACTIONisanacceptablealternativetoCASEAKCELANEXPLORE™
FLUID.
Frontdriveaxle-Four-Wheeldrive(4WD)-Standardduty
StandardandSCWPspecication
(factoryll):
TUTELATRANSAXLEFLUIDSAE80W-140
Capacity:
Differential7.7L(8.1USqt)
Eachplanetaryhub
0.5L(0.5USqt)
Frontdriveaxle-Four-Wheeldrive(4WD)–Heavyduty(12.5/80x18tireonly)
StandardandSCWPspecication
(factoryll):
TUTELATRANSAXLEFLUIDSAE80W-140
Capacity:
Differential8.6L(9.1USqt)
Eachplanetaryhub
1.0L(1.1USqt)
Rearaxle(differentialandhubs)
StandardandSCWPspecication
(factoryll):
TUTELATRANSAXLEFLUIDSAE80W-140
Capacity:
13.6L(14.4USqt)
