CURRENT CONDITION CHK3
This screen is used to verify that the controller is receiving the input from
the listed switches and signals.
• SW1: Upper pressure switch, travel pressure switch, swing pressure
switch and hammer pressure switch.
• SW2: Engine oil pressure switch and coolant level switch.
• SW3: Battery charge.
• SW4: Cushion switch (off/on), free swing switch and one touch idle
switch.
• SW5: Swing lock switch, emergency stop switch, work light and wiper
switch.
• SW6: Window washer switch, travel alarm and hammer mode switch.
• SW7: Key switch.
CHK MODE 2 H
3 SW4 0 0 0 0
SW1 0 0 0 0 SW5 0 0 0 0
SW2 0 0 0 0 SW6 0 0 0 0
SW3 0 0 0 0 SW7 0 0 0 0
To Next Page
