INTRODUCTION
with2.62m(8.60ft)Arm,0.62m³Bucket,600mm(23.622in)grousershoe
Diggingforce(with0.62m³bucket)(ISO6015)
[2.62m(8.60ft)]Arm[3.05m(10.01ft)]Arm[2.23m(7.32ft)]Arm
Armdiggingforce79kN(17760lb)72kN(16186lb)90kN(20232.8lb)
Withautopowerup84kN(18884lb)77kN(17310lb)95kN(21356.8lb)
Bucketdiggingforce112kN(25179lb)112kN(25179lb)112kN(25178.6lb)
Withautopowerup118kN(26527lb)118kN(26527lb)118kN(26527.5lb)
Dimensions
[2.62m(8.60ft)]Arm[3.05m(10.01ft)]Arm[2.23m(7.32ft)]Arm
Overalllength(withoutattachment)4430mm(174.409in)4430mm(174.409in)4430mm(174.4in)
Overalllength(withattachment)8460mm(333.071in)8520mm(335.433in)8490mm(334.3in)
Overallheight(totopofboom)2960mm(116.535in)3130mm(123.228in)3000mm(118.1in)
Overallheight(totopofCab)2970mm(116.929in)2970mm(116.929in)3050mm(120.1in)
Overallheight(totopofhandrail)3260mm(128.346in)3260mm(128.346in)3260mm(128.3in)
Upperstructureoverallwidth
2530mm(99.606in)2530mm(99.606in)2530mm(99.606in)
Swing(rearend)radius2430mm(95.669in)2430mm(95.669in)2430mm(95.669in)
Clearanceheightunderupper
structure
1020mm(40.157in)1020mm(40.157in)1020mm(40.157in)
Minimumgroundclearance420mm(16.535in)420mm(16.535in)420mm(16.535in)
Wheelbase(Centertocenterof
wheels)3190mm(125.591in)3190mm(125.591in)3190mm(125.591in)
Crawleroveralllength3990mm(157.087in)3990mm(157.087in)3990mm(157.087in)
Trackgauge1990mm(78.346in)1990mm(78.346in)1990mm(78.346in)
Undercarriageoverallwidth[with
600mm(23.622in)shoes]2590mm(101.969in)2590mm(101.969in)2590mm(101.969in)
Crawlertracksheight920mm(36.220in)920mm(36.220in)990mm(38.976in)
Workingranges
[2.62m(8.60ft)]Arm[3.05m(10.01ft)]Arm[2.23m(7.32ft)]Arm
Boomlength
5150mm(202.756in)5150mm(202.756in)5150mm(202.756in)
Bucketradius
1350mm(53.150in)1350mm(53.150in)1350mm(53.150in)
Bucketwristaction
178°178°178°
MaximumreachatGRP
8870mm(349.213in)9220mm(362.992in)8490mm(334.252in)
Maximumreach
9040mm(355.906in)9380mm(369.291in)8670mm(341.339in)
Max.diggingdepth
6060mm(238.583in)6490mm(255.512in)5660mm(222.835in)
Max.diggingheight
9240mm(363.780in)9290mm(365.748in)9010mm(354.724in)
Max.dumpingheight
6610mm(260.236in)6690mm(263.386in)6380mm(251.181in)
4799619620/05/2016
23
