Case CX160D - General Specification

INTRODUCTION
Groundpressure
0.041MPa(5.947psi)
with2.62m(8.60ft)Arm,0.68m³Bucket,600mm(23.622in)grousershoe
Diggingforce(with0.68m³bucket)(ISO6015)
[2.62m(8.60ft)]Arm[3.05m(10.01ft)]Arm[2.23m(7.32ft)
Armdiggingforce79kN(17760lb)72kN(16186lb)90kN(20233lb)
Withautopowerup84kN(18884lb)77kN(17310lb)95kN(21357lb)
Bucketdiggingforce112kN(25179lb)112kN(25179lb)112kN(25179lb)
Withautopowerup118kN(26527lb)118kN(26527lb)118kN(26527lb)
Dimensions
[2.62m(8.60ft)]Arm[3.05m(10.01ft)]Arm[2.23m(7.32ft)
Overalllength(withoutattachment)4520mm(177.953in)4520mm(177.953in)4520mm(177.953in)
Overalllength(withattachment)8460mm(333.071in)8510mm(335.039in)8490mm(334.252in)
Overallheight(totopofboom)2960mm(116.535in)3120mm(122.835in)3000mm(118.110in)
Overallheight(totopofCab)3070mm(120.866in)3070mm(120.866in)3070mm(120.866in)
Overallheight(totopofhandrail)3280mm(129.134in)3280mm(129.134in)3280mm(129.134in)
Upperstructureoverallwidth
2530mm(99.606in)2530mm(99.606in)2530mm(99.606in)
Swing(rearend)radius2470mm(95.669in)2470mm(95.669in)2470mm(95.669in)
Clearanceheightunderupper
structure
1040mm(40.945in)1040mm(40.945in)1040mm(40.945in)
Minimumgroundclearance440mm(17.323in)440mm(17.323in)440mm(17.323in)
Wheelbase(Centertocenterof
wheels)3370mm(132.677in)3370mm(132.677in)3370mm(132.677in)
Crawleroveralllength4180mm(164.567in)4180mm(164.567in)4180mm(164.567in)
Trackgauge2200mm(86.614in)2200mm(86.614in)2200mm(86.614in)
Undercarriageoverallwidth[with
600mm(23.622in)shoes]2800mm(110.236in)2800mm(110.236in)2800mm(110.236in)
Crawlertracksheight925mm(36.417in)925mm(36.417in)925mm(36.417in)
Workingranges
[2.62m(8.60ft)]Arm[3.05m(10.01ft)]Arm[2.23m(7.32ft)]Arm
Boomlength
5150mm(202.756in)5150mm(202.756in)5150mm(202.756in)
Bucketradius
1350mm(53.150in)1350mm(53.150in)1350mm(53.150in)
Bucketwristaction
178°178°178°
MaximumreachatGRP
8870mm(349.213in)9210mm(362.598in)8490mm(334.252in)
Maximumreach
9040mm(355.906in)9380mm(369.291in)8670mm(341.339in)
Max.diggingdepth
6040mm(237.795in)6470mm(254.724in)5650mm(222.441in)
Max.diggingheight
9250mm(364.173in)9300mm(366.142in)9030mm(355.512in)
Max.dumpingheight
6630mm(261.024in)6710mm(264.173in)6400mm(251.969in)
4799619620/05/2016
27
