Case CX160D - Page 33

INTRODUCTION
Operatorenvironment
Operator'scab
Smoothandroundshapedesigncab,fabricatedbypresswork
Safetyglassforallwindows
Shock-lesscabsuspensionby4-pointuidmounting
Slidingfrontwindowwithautolock
Built-intypefull-colorLCDmonitordisplay
Membraneswitchonmonitordisplay
Windshieldwiper&washer
Floormat
Polycarbonateroofhatch&Sunshade
Autoair-conditioner
Raindeector
Sunvisor
Roll-overprotectivestructure(ROPS)
TopguardOPGlevel1(inCABstructure)
TopguardOPGlevel2(additionalguard)
Operator'sseat
Lowfrequencymechanicalsuspensionwithhelicalspringsanddoubleactinghydraulicdamper.(Achieves
ISO7096incategoryEM6)
Withfollowingfeatures
ManualweightadjustmentBackrestangleadjustment
Seatheightadjustment
Adjustablepivotingarmrestslinkedtoconsoles
AdjustableheadrestRetractableseatbelt
Adjustablelumbarsupport
Controlconsolesadjustindependentlyofseat
Others
Rearviewmirror(Cabside&Rightside)
RearviewCamera
Undercarriage
Travelmotor
Variabledisplacementaxialpistonmotor
BrakeMechanicaldiscbrake
Hydraulicservicebrake
Brakevalve
Finaldrive
Planetarygearreduction
High
5.4km/h(3.4mph)(Automatictravelspeed
shifting)
Travelspeeds
Low
2.8km/h(1.7mph)
Drawbarpull160kN(35969lb)
Numberofcarrierrollers(eachside)
2
Numberoftrackrollers(eachside)
7
Numberofshoes(eachside)
46
Typeofshoe
Triplegrousershoe
Linkpitch190mm(7.480in)
Widthofshoe
600mm(23.622in)(S.T.D)
Grade-ability70%(35°)
Mass
Operatingmass18500kg(40786lb)
with2.62m(8.60ft)Arm,0.68m³Bucket,600mm(23.622in)grousershoe,operator,lubricant,coolant
andfullfueltankandtopguardOPGlevel2
Shippingmass17600kg(38801lb)
Operatingmass-(operatormass[75kg(165.35lb)]+90%offuelmass[225kg(496.040lb)]+
bucketmass[521kg(1148.608lb)]
Counterweightmass3170kg(6989lb)
4799619620/05/2016
26
