Case CX160D - General Specification

INTRODUCTION
Engine-related
Engine
EnginemodelnameIsuzu4JJ1Xdieselengine
Enginetype
4-cycle,water-cooled,overheadcamshaft,verticalin-line,direct
injectiontype(electronicscontroltype)
Numberofcylinders-diameter-stroke∅95.4mm(3.756in)-104.9mm(4.130in)
Totaldisplacement
2999L(792.252USgal)
Compressionratio
17.5
Ratedoutput
80.6-85.8kW(109.59-116.66Hp)/2200RPM
Maximumtorque
349N·m(257.41lbft)/1800RPM
Enginedryweight
About333kg(734.139lb)
Oilpan
Alldirectionallowableinclinationangle0.61rad
Coolingfan∅550mm(21.654in)-suctiontype-8bladesresin
Withbellmouth-typefanguide
Pulleyratio
0.95(reduction)
Charginggenerator24V50AACtype
Startermotor24V4.0kW(5.4Hp)reductiontype
Coolantcapacity6.0L(1.585USgal)
OilpancapacityMax:15L(3.96USgal) Min:11L(2.91USgal)(excludingoillter)
DirectionofrotationRight(viewedfromfanside)
Aircleaner(doubleelement)
Manufacturer
NipponDonaldson,Ltd.
Element(outer)-Filteringareasize3.24m²(5022.01in²)
Element(inner)-Filteringareasize0.08m²(124.00in²)
Weight
2.7kg(5.952lb)
Radiator
ManufacturerTokyoRadiatorMFG.Co.,Ltd.
Weight
17.5kg(38.5809lb)
Oilcooler
Oilvolume6.9l(1.823USgal)
Weight
8.8kg(19.4007lb)
Radiator
Coolantcapacity6.3l(1.664USgal)
Weight
6.3kg(13.8891lb)
Aircooler
Capacity4.4l(1.162USgal)
Weight
0.7kg(1.5432lb)
Fuelcooler
Capacity0.2l(0.053USgal)
Totalweight
72.5kg(159.835lb)
SCR
ManufacturerTokyoRadiatorMFG.Co.,Ltd.
Ureacapacity
75.1L(19.84USgal)
Weight
9.2kg(20.283lb)
