INTRODUCTION
Cushionvalve(heatcircuit,withshuttlevalve)
ManufacturerKYB-YSCO.,LTD.
Portsize
G3/8(A-Pports)
G1/4(Q-Vports)
Weight
12.5kg(27.5578lb)
Selectorvalve
2WAY
ManufacturerNishinaIndustrialCo.,Ltd.
Ratedow25l/min(6.604USgpm)
OperatingmethodD(ISO),C(JD)
Portsize
G3/8
Weight
4kg(8.8185lb)
Centerjoint
OperatingpressureHigh-pressurepassage(ABCD)34.3MPa(4975psi)
Drainport(E)0.5MPa(72.52psi)
Pilotport(F)3.9MPa(566psi)
Flowamount
High-pressurepassage(ABCD)234L/min(61.816USgpm)
Drainport(E)10L/min(2.642USgpm)
Pilotport(F)21L/min(5.548USgpm)
PortAForwardright
G3/4
PortB
ForwardleftG3/4
PortC
Backwardright
G3/4
PortD
BackwardleftG3/4
PortEDrainport
G1/2
PortFPilotport
G1/4
Weight
29.5kg(65.04lb)
