INTRODUCTION
NOTE:Theweightsshownhereareapproximatevalues.
Standalonepartweight
Partname
Weight
1Travelunit
637kg(1404.345lb)
2
Take-uproller96kg(211.644lb)
3
Upperroller18kg(39.683lb)
4Lowerroller
36kg(79.366lb)
5
Swingunit230kg(507.063lb)
6
Turntablebearing
243kg(535.723lb)
7
Engine
415kg(914.918lb)
8Radiator
108kg(238.099lb)
9
Hydraulicpump
109kg(240.304lb)
10Fueltank
150kg(330.693lb)
11
Hydraulicoiltank
125kg(275.578lb)
12
Controlvalve
169kg(372.581lb)
13
Centerjoint29kg(63.934lb)
14Boom
1072kg(2363.355lb)
Trackweight(perside)
Partname
Weight
1
600mm(23.62in)grousertrack1547kg(3410.551lb)
2
700mm(27.56in)grousertrack1406kg(3099.699lb)
3
500mm(19.69in)grousertrack1358.5kg(2994.980lb)
Armweight
Partname
Weight
1
Standardarm(EM301)470.9kg(1038.157lb)
2
Standardarm(EM3O1PL)522.1kg(1151.033lb)
3
Standardarm(EM3O12)475.6kg(1048.519lb)
4
Standardarm(EM3O12PL)526.8kg(1161.395lb)
5
Longarm(EM3O1)549.5kg(1211.440lb)
6
Longarm(EM3O1PL)603.0kg(1329.387lb)
7
Longarm(EM3O12)554.2kg(1221.802lb)
8
Longarm(EM3O12PL)607.7kg(1339.749lb)
4799619620/05/2016
