INTRODUCTION
Diggingforce(with2.0m³bucket)(ISO6015)
3.38m(11.0892ft)Arm2.53m(8.3005ft)Arm
Armdiggingforce201kN(45187lb)246kN(55303lb)
Withautopowerup220kN(49458lb)269kN(60474lb)
Bucketdiggingforce247kN(55528lb)247kN(55528lb)
Withautopowerup270kN(60698lb)270kN(60698lb)
Dimensions
3.38m(11.0892ft)Arm2.53m(8.3005ft)Arm
Overalllength(withoutattachment)6450mm(253.937in)6450mm(253.937in)
Overalllength(withattachment)12060mm(474.803in)12090mm(475.984in)
Overallheight(withattachment)3680mm(144.882in)3720mm(146.457in)
Overallheight(totopofheadguard)3550mm(139.764in)3550mm(139.764in)
Overallheight(totopofguardrail)3800mm(149.606in)3800mm(149.606in)
Upperstructureoverallwidth(without
catwalks)
3060mm(120.472in)3060mm(120.472in)
Upperstructureoverallwidth(with
catwalks)
3590mm(141.339in)3590mm(141.339in)
Swing(rearend)radius3730mm(146.850in)3730mm(146.850in)
Clearanceheightunderupper
structure
1480mm(58.268in)1480mm(58.268in)
Minimumgroundclearance
720mm(28.346in)720mm(28.346in)
Wheelbase(Centertocenterof
wheels)
4400mm(173.228in)4400mm(173.228in)
Crawleroveralllength5450mm(214.567in)5450mm(214.567in)
Trackgauge(extended)2890mm(113.780in)2890mm(113.780in)
Trackgauge(retracted)2390mm(94.094in)2390mm(94.094in)
Undercarriageoverallwidth
(extended)[with600mm(23.622in)
shoes]
3490mm(137.402in)3490mm(137.402in)
Undercarriageoverallwidth
(retracted)[with600mm(23.622in)
shoes]
2990mm(117.717in)2990mm(117.717in)
Crawlertracksheight1220mm(48.031in)1220mm(48.031in)
Workingranges
3.38m(11.0892ft)Arm2.53m(8.3005ft)Arm
Boomlength
6980mm(274.803in)6980mm(274.803in)
Bucketradius
1840mm(72.441in)1840mm(72.441in)
Bucketwristaction
176°176°
MaximumreachatGRP
11720mm(461.417in)10980mm(432.283in)
Maximumreach
11970mm(471.260in)11220mm(441.732in)
Max.diggingdepth
7570mm(298.031in)6720mm(264.567in)
Max.diggingheight
11250mm(442.913in)11000mm(433.071in)
Max.dumpingheight
7840mm(308.661in)7560mm(297.638in)
