Case CX490D - Primary Machine Operation Controls

INTRODUCTION
Weight
CX490DCrawlerexcavatorsLCversion(TIER4FINAL)-EUMarket
WE
CX500DCrawlerexcavatorsLCMassExcavatorversion(TIER4FINAL)
-EUMarket
WE
Dividedweight(LCStandardundercarriage)
C156F60E1
Code
Partname
Weight
A
Operatingweight47299kg(104276.445lb)
B
Uppercomponent(includingcounterweightand
turntablebearing)
22224kg(48995.533lb)
C
Counterweight10022kg(22094.728lb)
D
Lowercomponent(withgrousershoe)16654kg(39813.280lb)
E
Mainunitweight
38878kg(85711.318lb)
FAttachment
8345kg(18397.576lb)
G
Boom(includingcylinder)5600kg(12345.887lb)
H
Arm(includingcylinderandlinkage)2749kg(6060.508lb)
