INTRODUCTION
Dimension
CX490DCrawlerexcavatorsLCversion(TIER4FINAL)-EUMarket
WE
Standardarm[3.38m(11.09ft)]
NOTE:Thevaluesusedinthisdocumentaresubjecttochangewithoutnoticeduetoadesignchangeorotherrea-
sons.
NOTE:Thevaluesindicatedinthediagramincludetheshoelugheight(a)[36mm(1.417in)].
1D349C3D1
(b)Withcatwalk-option
4793781129/02/2016
60
