INTRODUCTION
Bucketweight(CX500DRTC)
Rockbuckets
Capacity
ISO7451(Heaped)
WidthMass
1.75m³(2.29yd³)1350mm(53in)2270kg(5004lb)
2.00m³(2.62yd³)1500mm(59in)2380kg(5247lb)
2.33m³(3.05yd³)1700mm(67in)2500kg(5512lb)
2.50m³(3.27yd³)1800mm(71in)2640kg(5820lb)
2.78m³(3.64yd³)2000mm(79in)2900kg(6393lb)
ExtremeRockbuckets
Capacity
ISO7451(Heaped)
WidthMass
1.75m³(2.29yd³)1350mm(53in)2450kg(5401lb)
2.00m³(2.62yd³)1500mm(59in)2570kg(5666lb)
2.33m³(3.05yd³)1700mm(67in)2700kg(5952lb)
2.50m³(3.27yd³)1800mm(71in)2850kg(6283lb)
2.78m³(3.64yd³)2000mm(79in)3150kg(6945lb)
NOTE:RefertotheOperator’sManualfordirecttbucketsapplicationasfunctionofthearm.
4793781129/02/2016
59
