INTRODUCTION
Cylinder
Boomcylinder
Manufacturer
KYBCorporation
Cylinderbore∅170mm(6.693in)
Roddiameter
∅115mm(4.528in)
Maximumretractedlength
2230mm(87.795in)
Stroke
1550mm(61.024in)
Weight
400kg(881.849lb)
Armcylinder
Manufacturer
KYBCorporation
Cylinderbore∅190mm(7.480in)
Roddiameter
∅130mm(5.118in)
Maximumretractedlength
2688mm(105.827in)
Stroke
1920mm(75.591in)
Weight
631kg(1391.117lb)
Bucketcylinder
Manufacturer
KYBCorporation
Cylinderbore∅165mm(6.496in)
Roddiameter
∅115mm(4.528in)
Maximumretractedlength
1972mm(77.638in)
Stroke
1285mm(50.591in)
Weight
380kg(837.757lb)
