INTRODUCTION
with2.53m(8.3005ft)Arm,2.0m³Bucket,600mm(23.622in)grousershoe
0.085MPa(12.329psi)
Diggingforce(with3.0m³bucket)
2.53m(8.3005ft)Arm
Armdiggingforce245kN(55078lb)
Withautopowerup267kN(60024lb)
Bucketdiggingforce287kN(64520lb)
Withautopowerup313kN(70365lb)
Dimensions
2.53m(8.3005ft)Arm
Overalllength(withoutattachment)6450mm(253.937in)
Overalllength(withattachment)11680mm(459.843in)
Overallheight(withattachment)3800mm(149.606in)
Overallheight(totopofheadguard)3400mm(133.858in)
Overallheight(totopofguardrail)3650mm(143.701in)
Upperstructureoverallwidth(withoutcatwalks)3060mm(120.472in)
Upperstructureoverallwidth(withcatwalks)3590mm(141.339in)
Swing(rearend)radius3730mm(146.850in)
Clearanceheightunderupperstructure1330mm(52.362in)
Minimumgroundclearance
535mm(21.063in)
Wheelbase(Centertocenterofwheels)4400mm(173.228in)
Crawleroveralllength5450mm(214.567in)
Trackgauge
2750mm(108.268in)
Undercarriageoverallwidth[with600mm(23.622in)
shoes]
3350mm(131.890in)
Crawlertracksheight1240mm(48.819in)
Workingranges
2.53m(8.3005ft)Arm
Boomlength
6550mm(257.874in)
Bucketradius
1840mm(72.441in)
Bucketwristaction
160°
MaximumreachatGRP
10550mm(415.354in)
Maximumreach
10800mm(425.197in)
Max.diggingdepth
6490mm(255.512in)
Max.diggingheight
10550mm(415.354in)
Max.dumpingheight
7160mm(281.890in)
