INTRODUCTION
Intercoolercapacity
40.0kW
ntypeStraightn
nspace
2.0mm(0.08in)
Fuelcoolercapacity
3.72kW
ntypeCorrugatedn(wavytype)
nspace
2.25mm(0.09in)
Coolingfandrivesystem
Pump
1gearpump
Motor
Fixeddisplacementaxialpistonmotor
Filters
Suctionlter
105μm
Returnlter
6μm
Pilotlinelter
8μm
Hydrauliccontrols
Boom/Arm/Bucket/SwingPilotpressurecontrolsystem(ISOcontrolpattern)
Travel
Pilotpressurecontrolsystem
SP-mode
H-mode
Workmodeselect
Auto-mode
Travelmodeselect
2-speedtravel
Attachmentcushioncontrol
Hydrauliclock(gatelock,leftsidetiltconsole)
Fanreverserotationsystem
Electricalsystem
Enginecontrol
Dialtypethrottlecontrol
Onetouchidle/Autodeceleration/Autoidleshutdownsystem
Emergencystop
Monitorsystem
Messagedisplay(Caution,condition,etc.)
Workmodedisplay(SP ,H,Auto)
Machinecondition(Powerboost,etc.)
Alarmdisplayandbuzzer
Watertemperature
Hydraulicoiltemperature
Fuellevel
Diagnosissystem
Rearviewcameraimage
Ureawaterlevel
Wireharness
Waterprooftypeconnector
Safety
Doublehorn
Battery
2X12V128A·h/5HR
Lights
Upper
24V70WX1
Boom24V70WX2
Workinglight
Cab
24V70WX2
Operator'scabroom
24V70WX1
4793781129/02/2016
36
