INTRODUCTION
with2.53m(8.3005ft)Arm,2.0m³Bucket,600mm(23.622in)grousershoe
0.087MPa(12.619psi)
Diggingforce(with3.0m³bucket)
2.53m(8.3005ft)Arm
Armdiggingforce245kN(55078lb)
Withautopowerup267kN(60024lb)
Bucketdiggingforce287kN(64520lb)
Withautopowerup313kN(70365lb)
Dimensions
2.53m(8.3005ft)Arm
Overalllength(withoutattachment)6450mm(253.937in)
Overalllength(withattachment)11680mm(459.843in)
Overallheight(withattachment)3840mm(151.181in)
Overallheight(totopofheadguard)3550mm(139.764in)
Overallheight(totopofguardrail)3800mm(149.606in)
Upperstructureoverallwidth(withoutcatwalks)3060mm(120.472in)
Upperstructureoverallwidth(withcatwalks)3590mm(141.339in)
Swing(rearend)radius3730mm(146.850in)
Clearanceheightunderupperstructure1480mm(58.268in)
Minimumgroundclearance
720mm(28.346in)
Wheelbase(Centertocenterofwheels)4400mm(173.228in)
Crawleroveralllength5450mm(214.567in)
Trackgauge(extended)2890mm(113.780in)
Trackgauge(retracted)2390mm(94.094in)
Undercarriageoverallwidth(extended)[with600mm
(23.622in)shoes]
3490mm(137.402in)
Undercarriageoverallwidth(retracted)[with600mm
(23.622in)shoes]
2990mm(117.717in)
Crawlertracksheight1220mm(48.031in)
Workingranges
2.53m(8.3005ft)Arm
Boomlength
6550mm(257.874in)
Bucketradius
1840mm(72.441in)
Bucketwristaction
160°
MaximumreachatGRP
10520mm(414.173in)
Maximumreach
10800mm(425.197in)
Max.diggingdepth
6340mm(249.606in)
Max.diggingheight
10700mm(421.260in)
Max.dumpingheight
7310mm(287.795in)
