INTRODUCTION
Operationremotecontrolvalvecontroldiagram
SMIL15CEXY353EB2
1
Pushrodstroke[mm(in)]
5
Secondarypressure
2
Operatingangle[deg.]
6
Independentoperatingtorque(Port1)
3
Secondarypressure[MPa(psi)]
7
Independentoperatingtorque(Port3)
4
Operatingtorque[Nm]
SMIL15CEXY354EB3
1
Pushrodstroke[mm(in)]
4
Operatingtorque[Nm]
2
Operatingangle[deg.]
5
Secondarypressure
3
Secondarypressure[MPa(psi)]
6Independentoperatingtorque
Travelremotecontrolvalvecontroldiagram
SMIL15CEXY355EB4
1
Pushrodstroke[mm(in)]
4
Operatingtorque[Nm]
2
Operatingangle[deg.]
5
Secondarypressure
3
Secondarypressure[MPa(psi)]
6Independentoperatingtorque
