Case CX75SR TIER 3 - Page 32

Lep SC75SRCX80-1002-0NA Issued 03-08
1002-23
CX80
Model MONO BOOM
Boom length 3500 mm (137.79 in)
Arm type Standard
1.710 mm
(67.32 in)
Long
2.120 mm
(83.46 in)
Arm (dipper) length
1710 mm
(67.32 in)
2120 mm
(83.46 in)
Bucket capacity
Heaped 0.28 m
3
(Leveled 0.20 m
3
)
Heaped 0.22 m
3
(Leveled 0.16 m
3
)
Bucket width 730 mm (28.74 in) 600 mm (23.62 in)
Bucket width with side cutter 804 mm (31.65 in) 673 mm (26.50 in)
Bucket weight with side cutter 204 kg (449.74 lb) 178 kg (392.42 lb)
Bucket radius 1050 mm (41.34 in) 1050 mm (41.34 in)
Bucket wrist angle 177°
Maximum digging radius
7030 mm
( 276.77 in)
7400 mm
(291.33 in)
Maximum digging radius at ground line
6390 mm
(275.19 in)
7270 mm
(286.21 in)
Maximum digging depth
4180 mm
(164.56 in)
4590 mm
(180.70 in)
Maximum vertical straight wall digging radius
3080 mm
(121.25 in)
3550 mm
(139.76 in)
Maximum digging height
6390 mm
(251.57 in)
6600 mm
(259.84 in)
Maximum dump height
4390 mm
(172.83 in)
4600 mm
(181.10 in)
Minimum swing radius at front
2750 mm
(108.26 in)
2910 mm
(114.56 in)
Height for minimum swing radius at front
5060 mm
(199.21 in)
5080 mm
(199.99 in)
