Major component weight (CX80)
Weight (kg) information is approximate
Symbol Component Name
A Operating weight 8470 (18673 lbs)
B Upper mechanism (including counterweight and turntable bearing 4527 (9980 lbs)
C Counterweight 1237 (2727 lbs)
D Lower mechanism (with standard grouser shoe) 2801 (7175 lbs)
E Main Unit Weight 7328 (16155 lbs)
F Attachments 1063 (2343 lbs)
G Boom (including cylinders) 595 (1311 lbs)
H Arm (dipper) (including cylinders and linkage) 262 (577 lbs)
I Blade 332 (732 lbs)
A
C
B
ED
F
G
H
I
