Lep SC75SRCX80-1002-0NA Issued 03-08
1002-29
Upper roller
Dimensions
AQ19002-002A
Gauge
Measure with a slide caliper.
Ø a
Ø b
Mark Dimension (mm)
Ø a
Standard 80
Limit 70
Ø b (shaft)
Standard 30
Limit ---
