Case CX75SR TIER 3 - Page 39

Lep SC75SRCX80-1002-0NA Issued 03-08
1002-30
Lower roller
Dimensions
AQ19002-003A
Gauge
AQ19002-033A
Ø a
b
d
f
g
Øe
Mark Dimension (mm) Mark Dimension (mm)
Ø a
Standard 118
Ø e (ring)
Standard 40
Limit 112 Limit 40.8
b
Standard 13
f
Standard 38
Limit 11 Limit 37.6
d
Standard 44
g
Standard 30.2
Limit 40 Limit 29.7
Ø e (shaft)
Standard 40
Limit 39
170
150.5 - 151.5
44
R
6
137
6.5
50
1
5
°
2
-
R
3
2
-
R
4
4
-
R
5
3
°
105.7 - 106.3
1
.
5
°
