Case CX75SR TIER 3 - Work Unit

Lep SC75SRCX80-1002-0NA Issued 03-08
1002-22
Work Unit
Model..................................................................................................................................................Backhoe attachment
Components / dimensions / working dimensions
CX75SR
Model MONO BOOM OFFSET BOOM
Boom length 3870 mm (152.36 in)
Arm type Standard
1.710 mm
(67.32 in)
Long
2.120 mm
(83.46 in)
Standard
1.750 mm
(68.90 in)
Arm (dipper) length
1710 mm
(67.32 in)
2120 mm
(83.46 in)
1740 mm
(68.50 in)
Bucket capacity
Heaped 0.28 m
3
(Leveled 0.20 m
3
)
Heaped 0.22 m
3
(Leveled 0.16 m
3
)
Heaped 0.28 m
3
(Leveled 0.20 m
3
)
Bucket width 730 mm (28.74 in) 600 mm (23.62 in) 730 mm (28.74 in)
Bucket width with side cutter 804 mm (31.65 in) 673 mm (26.50 in) 804 mm (31.65 in)
Bucket weight with side cutter 204 kg (449.74 lb) 178 kg (392.42 lb) 204 kg (449.74 lb)
Bucket radius 1450 mm (57.08 in) 1050 mm (41.34 in) 1450 mm (57.08 in)
Bucket wrist action 177°
Maximum digging radius
6520 mm
(256.69 in)
6900 mm
(271.65 in)
6080 mm
(239.40 in)
Maximum digging radius at ground line
6390 mm
(251.57 in)
6770 mm
(266.53 in)
6360 mm
(250.39 in)
Maximum digging depth
4140 mm
(162.99 in)
4540 mm
(178.74 in)
4190 mm
(164.96 in)
Maximum vertical straight wall digging radius
3640 mm
(143.31 in)
4100 mm
(161.42 in)
4580 mm
(180.31 in)
Maximum digging height
7330 mm
(288.58 in)
7620 mm
(300 in)
7195 mm
(283.27 in)
Maximum dump height
5250 mm
(206.69 in)
5540 mm
(218.10 in)
5150 mm
(202.75 in)
Minimum swing radius at front
1785 mm
(70.27 in)
2085 mm
(82.08 in)
2230 mm
(87.79 in)
Height for minimum swing radius at front
5620 mm
(221.26 in)
5650 mm
(222.44 in)
5700 mm
(224.41 in)
