Case CX75SR TIER 3 - Dimensions and Wear Limit of the Track Assembly; Sprocket

Lep SC75SRCX80-1002-0NA Issued 03-08
1002-27
DIMENSIONS AND WEAR LIMIT OF THE TRACK ASSEMBLY
Sprocket
Dimensions
CS01B512
Gauge
AQ19002-031A
Mark Dimension (mm)
a
Standard 35
Limit 30
Ø b
Standard 480.81
Limit 474.91
Ø c
Standard 533.61
Limit 527.61
Ø d
Standard 522.47
Limit ---
P
Standard 154
Limit ---
P
Ø d
Ø cØ b
a
185
48.89
25
3.9 3.9
1
7
.
1
°
1
7
.
1
°
153 - 155
R
3
t
o
6
4
0
.
7
°
21.6
82.8
70
15.1
9
0
°
1
2
.
7
°
R
2
8
.
7
R
5
3
.
8
R
2
0
.
8
