Case CX75SR TIER 3 - Idler Wheel

Lep SC75SRCX80-1002-0NA Issued 03-08
1002-28
Idler wheel
Dimensions
AQ19002-001A
Gauge
AQ19002-032A
Ø a
b
c
e
f
Ø d
Mark Dimension (mm)
Ø a
Standard 400
Limit 369
b
Standard 28
Limit 25
c
Standard 44
Limit 40
Ø d (shaft)
Standard 42
Limit 41
Ø d (bushing)
Standard 42
Limit 42.8
e
Standard 42
Limit 41.6
f
Standard 20
Limit 19.5
110
4
0
°
39 - 44
94 - 98
10
2
-
R
3
6
-
R
5
38.4
1
0
°
3
°
28
5
