Casio AP-200

– 14 –
10-5. Remove 3 screws and the M333-CNA3 PCB.
Pedal connector
Ferrite core
10-6. Remove 2 screws and the M333-CNA5 PCB.
11. Removing the M333-CNA3 PCB and M333-CNA5 PCB
11-1. Remove the screw and the Ferrite core.
11-2. Remove 2 screws and the Pedal connector.
